Carr Lane Swivel Pads
The heavy-duty swivel foot pivots to ensure even contact with sloped surfaces. Its large swivel ball offers a high load capacity with an 18° total swivel angle. Tapped-hole sizes range from 1/4-20 to 1"-8 (M6 to M20 in metric). These are available with both steel and Delrin® pads. The Delrin® pad prevents surface damage, though it has a lower load capacity compared to the steel pad. Tapped-hole sizes range from 1/4-20 to 5/8-11.
- Steel or Delrin® pad
- Metric and Imperial sizes
- Thread: 1/4-20 - 1-8 or M6 - M20
| Part Number | Material Number | Metric or Imperial | Pad Type | Thread | Nut Diameter | Price | Add to Parts List |
|---|---|---|---|---|---|---|---|
| CLM-20-SPA | Metric | Steel | M20 | 30mm | £26.55 £31.86 Inc. VAT |
|
|
| CLM-16-SPA | Metric | Steel | M16 | 24mm | £21.42 £25.70 Inc. VAT |
|
|
| CLM-12-SPA | Metric | Steel | M12 | 19mm | £19.66 £23.59 Inc. VAT |
|
|
| CLM-10-SPA | Metric | Steel | M10 | 17mm | £18.20 £21.84 Inc. VAT |
|
|
| CLM-8-SPA | Metric | Steel | M8 | 13mm | £17.45 £20.94 Inc. VAT |
|
|
| CLM-6-SPA | Metric | Steel | M6 | 10mm | £17.00 £20.40 Inc. VAT |
|
|
| CL-7-SPA | Imperial | Steel | 1"-8 | 1-3/8 | £24.71 £29.65 Inc. VAT |
|
|
| CL-6-SPA | Imperial | Steel | 3/4-10 | 1-1/16 | £18.86 £22.63 Inc. VAT |
|
|
| CL-2-SPA | Imperial | Steel | 5/16-18 | 9/16 | £12.09 £14.51 Inc. VAT |
|
|
| CL-5-SPA | Imperial | Steel | 5/8-11 | 7/8 | £14.50 £17.40 Inc. VAT |
|
|
| CL-1-SPA | Imperial | Steel | 1/4-20 | 1/2 | £12.24 £14.69 Inc. VAT |
|
|
| CL-4-SPA | Imperial | Steel | 1/2-13 | 3/4 | £14.42 £17.30 Inc. VAT |
|
|
| CL-3-SPA | Imperial | Steel | 3/8-16 | 5/8 | £15.75 £18.90 Inc. VAT |
|
| Part Number | Material Number | Metric or Imperial | Pad Type | Thread | Nut Diameter | Price | Add to Parts List |
|---|---|---|---|---|---|---|---|
| CL-2-SPAN | Imperial | Delrin | 5/16-18 | 9/16 | £14.26 £17.11 Inc. VAT |
|
|
| CL-5-SPAN | Imperial | Delrin | 5/8-11 | 7/8 | £17.13 £20.56 Inc. VAT |
|
|
| CL-1-SPAN | Imperial | Delrin | 1/4-20 | 1/2 | £13.71 £16.45 Inc. VAT |
|
|
| CL-4-SPAN | Imperial | Delrin | 1/2-13 | 3/4 | £16.53 £19.84 Inc. VAT |
|
|
| CL-3-SPAN | Imperial | Delrin | 3/8-16 | 5/8 | £18.11 £21.73 Inc. VAT |
|
Carr Lane Swivel Pads
The heavy-duty swivel foot pivots to ensure even contact with sloped surfaces. Its large swivel ball offers a high load capacity with an 18° total swivel angle. Tapped-hole sizes range from 1/4-20 to 1"-8 (M6 to M20 in metric). These are available with both steel and Delrin® pads. The Delrin® pad prevents surface damage, though it has a lower load capacity compared to the steel pad. Tapped-hole sizes range from 1/4-20 to 5/8-11.
Options:
- Choice of steel or Delrin® pad
- Metric and Imperial sizes
- Thread: 1/4-20 - 1-8 or M6 - M20
