Heypac Smoothing Kits (Pulsation Dampeners)
Smoothing Kits (Pulsation dampeners) GX05, GX10 and GX20 Pumps Without Valve Manifolds
Heypac
HYQUIP & Heypac
Based in the United Kingdom, with a North American sales office and warehouse, plus a global network of distributors, the Heypac range is readily available around the world and is a trusted name in the fluid power industry. Thanks to the exemplary quality of their products Hyquip is honoured to act as an official supplier and distributor for the Heypac brand. Hyquip welcome Heypac enquiries from end users, original equipment machinery manufacturers, trade suppliers and resellers from all industrial sectors.
Who is Heypac?
Established over 40 years ago, Heypac has continually designed, manufactured and developed an excellent range of air driven pumps, hydro pneumatic pumps and air hydraulic pressure intensifiers, as well as the popular air driven hydraulic power unit. The Heypac range also includes zero leak directional control valves, pressure reducers, reservoirs, pulsation dampeners along with a selection of fluid and air filters. With some of their pressure boosters and intensifiers offering pressure of up to 840 bar (12,000 psi).
The Heypac product range is designed to meet the demanding needs of modern industries such as manufacturing, automotive, construction and more. These efficient and reliable solutions enable businesses to optimise their operations and empower industries worldwide.
Quality
Heypac are ISO 9001 registered and feels obliged to offer a continuous process of improvements, reflected within its products. HYQUIP's ISO 9001 certification also guarantees the compliance with standard guidelines.
Showing 1 to 12 of 30 items
Heypac Reservoirs, Level Switches and Extended Suction Tube Kits
Heypac Reservoirs and Level Switches - 10 and 30 Litre Heypac Reservoir Kit, Heypac Level Switches, Heypac Extended Suction Tube Kits
Heypac Manifold Blocks
Heypac Manifold Blocks - A range of manifold blocks that enable valves conforming to CETOP03/D03/NG6 standard to be mounted directly on to pumps.
- CETOP 03/D03/NG6 Manifold Block (vertical and horizontal)
- CETOP 03/D03/NG6 2 Station Manifold Block (horizontal)
Heypac Fluid Filtration
Heypac Fluid Filtration range enables you to tailor your HEYPAC pump to best suit your application and extend their long service life.
The range includes;
- Heypac Return Line Filter
- Heypac GX Return Line Filters
- Heypac KR Return Line Filters
Heypac Air Filter / Regulator Assembly
Hyquip supply the entire range of Heypac Air Filter / Regulator Assemblies.
Heypac Valves
Heypacs range of Valves to enable you to tailor your HEYPAC pump to best suit your application.
The range includes;
- W2 poppet zero leak directional valves
- Rotary lever Operated valves
- pressure reducing valves
K2R80 (80:1)
The HEYPAC K2R80 is a double acting, free piston, compressed air driven hydraulic pump of infinitely variable delivery for general use wherever a compressed air supply is available. The pump will cycle automatically according to system demand and stall under zero flow conditions with minimal energy consumption. The output flow and pressure depend upon the intensification ratio relative to the air supply pressure and volume.
Ratio fluid:air - 80:1
P max fluid bar (psi) - 680 (9840)
Q max fluid L/min (US gpm) - 0.5 (0.13)
Q max average fluid L/min (US gpm) - 0.17 (0.04)
K2R40 (40:1)
The HEYPAC K2R40 is a double acting, free piston, compressed air driven hydraulic pump of infinitely variable delivery for general use wherever a compressed air supply is available. The pump will cycle automatically according to system demand and stall under zero flow conditions with minimal energy consumption. The output flow and pressure depend upon the intensification ratio relative to the air supply pressure and volume.
Ratio fluid:air - 40:1
P max fluid bar (psi) - 340 (4920)
Q max fluid L/min (US gpm) - 1.2 (0.32)
Q max average fluid L/min (US gpm) - 0.35 (0.09)
K2R20 (20:1)
The HEYPAC K2R20 is a double acting, free piston, compressed air driven hydraulic pump of infinitely variable delivery for general use wherever a compressed air supply is available. The pump will cycle automatically according to system demand and stall under zero flow conditions with minimal energy consumption. The output flow and pressure depend upon the intensification ratio relative to the air supply pressure and volume.
Ratio fluid:air - 20:1
P max fluid bar (psi) - 170 (2460)
Q max fluid L/min (US gpm) - 2.5 (0.65)
Q max average fluid L/min (US gpm) - 0.7 (0.18)
K2R10 (10:1)
The HEYPAC K2R10 is a double acting, free piston, compressed air driven hydraulic pump of infinitely variable delivery for general use wherever a compressed air supply is available. The pump will cycle automatically according to system demand and stall under zero flow conditions with minimal energy consumption. The output flow and pressure depend upon the intensification ratio relative to the air supply pressure and volume.
Ratio fluid:air - 10:1
P max fluid bar (psi) - 85 (1230)
Q max fluid L/min (US gpm) - 5 (1.32)
Q max average fluid L/min (US gpm) - 1.4 (0.37)
K2R05 (5:1)
The HEYPAC K2R05 is a double acting, free piston, compressed air driven hydraulic pump of infinitely variable delivery for general use wherever a compressed air supply is available. The pump will cycle automatically according to system demand and stall under zero flow conditions with minimal energy consumption. The output flow and pressure depend upon the intensification ratio relative to the air supply pressure and volume.
Ratio fluid:air - 5:1
P max fluid bar (psi) - 42.5 (615)
Q max fluid L/min (US gpm) - 10 (2.65)
Q max average fluid L/min (US gpm) - 2.8 (0.74)
K2R02 (2:1)
The HEYPAC K2R02 is a double acting, free piston, compressed air driven hydraulic pump of infinitely variable delivery for general use wherever a compressed air supply is available. The pump will cycle automatically according to system demand and stall under zero flow conditions with minimal energy consumption. The output flow and pressure depend upon the intensification ratio relative to the air supply pressure and volume.
Ratio fluid:air - 2:1
P max fluid bar (psi) - 13.5 (200)
Q max fluid L/min (US gpm) - 15 (4)
Q max average fluid L/min (US gpm) - 4 (1)
