Carr Lane Eye Bolts

These precision locating pins feature a chamfered tip for effortless part loading and a shoulder that helps resist downward forces. Typically, one Round Pin and one Diamond Pin are used together to locate two machined holes in a workpiece or to align two fixture components without causing binding.  The head and shank diameters of the round locating pins are concentric to within .0005" TIR. These pins are available with head diameters ranging from 1/4" to 1" (6 to 20mm in metric).

• Head Diameter: 1/4 - 1 or 6mm - 20mm
• Metric and Imperial sizes
• Round and Diamond pins

The Slotted-Heel Clamp Strap includes a replaceable clamping pad secured with two screws. The padded straps also accommodate custom pads or other attachments. These straps feature a slot underneath, enabling them to slide back easily for straightforward loading. Additionally, each side has a tapped hole at the rear for installing a Finger Pin. These available to accommodate stud sizes ranging from1/4-20 to 1/2-13 (M6 to M12 in metric), each in a choice of strap lengths. This clamp strap can be ordered individually or in a complete clamp assembly. The available assemblies are assembly with spherical nut & washer, assembly with flange nut, assembly with hand knob & spherical washer, assembly with acorn nut & spherical washer, assembly with bar knob & spherical washer and assembly with cam handle & spherical washer.

Range of Carr Lane Assemblies including Hand Knob, Swivel Washer and Knob Shoe avaible in a variety of sizes

• Metric and Imperial sizes
• Thread: 1/4-20 - 3/4-10 or M6 - M20

Carr Lane Spherical nuts and washers is a combination of a nut and washer designed to compensate when a stud and clamping surface aren't perfectly perpendicular. This heavy-hex nut is similar to a Flange Nut but features a convex spherical radius underneath. The washer has a corresponding concave spherical radius to the nut. These are available in steel with thread sizes ranging from 1/4-20 to 1"-8 (M6 to M24 in metric), and in stainless steel with thread ranging sizes from 1/4-20 to 3/4-10.

• Imperial and Metric
• Steel and Stainless Steel
• Thread - 1/4-20 - 1"-8  M6 - M24

Carr Lane cam handles are designed for use with an Eye Bolt or a custom-made drawbar. The continuous-rise spiral cam locks firmly in place at any position. It is available to fit Eye Bolt sizes ranging from 1/4-20 to 3/4-10 (M6 to M20 in metric).

• Available inmetric and imperial
• Sizes ranging from 1/4-20 to 3/4-10 (M6 to M20 in metric).

Carr Lane hand knobs are designed to provide an efficient and ergonomic method of manually adjusting and controlling machinery and applications HYQUIP supply the full range of Carr Lane Knobs including Star, Hand and Fluted, available in a variety of materials and sizes.

• Star, Hand and Fluted Knob designs
• Metric and Imperial sizes
• Thread: #10-32 - 5/8-11 or M6 - M12

The palm grip knob handle features an ergonomic design that ensures a comfortable hold, significantly alleviating strain on the hands, wrists, and arms. This design helps minimize the risk of repetitive motion injuries. It has a textured, non-slip surface with a glare-resistant finish. Offered in a single handle size, it comes with tapped-hole options ranging from 1/4-20 to 3/8-16. The tapered, heavy-duty design offers an ideal grip as a handle or machine shift lever. It is available in three handle sizes, with tapped-hole options ranging from 1/4-20 to 1/2-13 (M6 to M10 in metric). The moulded brass insert enhances thread durability and strength. Additionally, all three handle sizes can be provided in solid plastic with a counterbored through-hole.

• Choice of handle sizes
• Metric and Imperial sizes available
