Enerpac FSH, FSM-Series Hydraulic and Mechanical Wedge Spreaders
The FSH, FSM-Series parallel wedge spreader offer controlled separation without bending or risk of slipping from the joint. These spreaders are ideally suited to flanged joint applications
- Maximum Operating Pressure: 700 bar
- Tip Clearance: 6 mm
- Maximum Spread: 80 mm
- Maximum Spread Force: 8-14 ton
Products
Downloads
Description
| Part Number | Material Number | Spreader Type | Price | Add to Parts List |
|---|---|---|---|---|
| FSH14 | Hydraulic | £2,560.00 £3,072.00 Inc. VAT |
|
|
| FSM8 | Mechanical | £2,259.00 £2,710.80 Inc. VAT |
|
Enerpac FSH, FSM-Series Hydraulic and Mechanical Wedge Spreaders
- Maximum Operating Pressure: 700 bar
- Tip Clearance: 6 mm
- Maximum Spread: 80 mm
- Maximum Spread Force: 8-14 ton
- Spreader Type: Hydraulic or Mechanical
Features:
- Enerpac industrial mechanical and hydraulic spreaders feature an integrated wedge concept: Friction-free, smooth and parallel wedge movement eliminates flange damage and spreading arm failure
- For maintenance, commissioning, shutdowns, testing and valve change outs
- Unique interlocking wedge design - no first step bending and risk of slipping out of joint
- Requires very small access gap of only 6 mm
- Stepped spreader arm design - each step can spread under full load
- Few moving parts mean durability and low maintenance
- Safety block SB-1 and ratchet spanner SW-22 included with FSM-8 mechanical wedge spreader
- Safety block SB-1 and Enerpac RC-102 single-acting cylinder included with FSH-14 hydraulic wedge spreader
Applications:
Enerpac FSH, FSM-Series Hydraulic Wedge Spreaders can be used for: pipe and flange repair, removing of elbows, couplers, gasket and metal seals replacement, maintenance/ replacement of valve and control equipment
