Slideway Locking Cylinders
ROEMHELD B1.490 Slideway Locking Cylinders: single acting without spring return max. operating pressure 500 bar
- Max. operating pressure 500 bar
- Max. locking force: 24.5 - 49 kN
- Piston stroke: 2 mm
Description
Downloads
Slideway Locking Cylinders - ROEMHELD B1.490
- Max. operating pressure 500 bar
- Max. locking force: 24.5 - 49 kN
- Piston stroke: 2 mm
Advantages:
- High locking forces with small dimensions
- Max. utilisation of available hydraulic pressure
- Locking pressure can be monitored
- Machine tool interlock as a function of the locking pressure
Application:
An economical solution to lock machine tool slideways is the direct locking method by means of hydraulic cylinders, powered from a central power system. Actuating controls of the various locking stations can be integrated with the machine tool control system.
