Enerpac MVP, WVP, V-series Hydraulic Sequence Valves

Enerpac MVP, WVP, V-series Hydraulic Sequence Valves

• Pressure: 350 bar
• Flow: 4 - 10,0 l/min

MVPM-5, WVP-5, MVPC-5 Sequence Valves

• Pressure setting between 35-350 bar for secondary circuit is secured with lock nut
• Mounting holes on WVP-5, manifold mounting ports on MVPM-5
• MVPC-5 features cartridge body

V-2000 Sequence Valves

• Pressure setting between 14-140 bar for secondary circuit
• Flag indicator appears everytime the valve is operated

Enerpac workholding sequence valves provide direct accurate pressure setting

Pressure dependent sequence control

Sequence valves:

Sequence valves block the oil to a secondary hydraulic circuit until pressure in the primary circuit reaches a preset level. The sequence valves have a built-in check system to allow the oil to flow back without external piping. Pressure settings for the V-2000 can be adjusted by screwing the slotted pin in or out. The pressure settings for the other models is adjusted by loosening the jam nut and turn the set screw to reach your setting.

Application:

The sequence valves can be mounted in-line or fixture mounted using mounting bolts. A typical application for the sequence valve would be to build pressure within work supports before the swing cylinders are applied to the supported part, to prevent deflection in the part.
