AZMF Size 8 to 28
External Gear Motors Type AZMF Sizes 8 to 28
- Platform F
- Fixed displacement
- Size 8 … 28
- Continuous pressure up to 250 bar
- Maximum start-up pressure up to 280 bar
Products
Downloads
Description
| Part Number | Material Number | Displacement | Price | Add to Parts List |
|---|---|---|---|---|
| AZMF-10-011USA20ML | 0511545601 | 11.0 cm3 / rev | £865.80 £1,038.96 Inc. VAT |
|
| AZMF-12-011UCB20PX-S0077 | 0511525611 | 11.0 cm3 / rev | £806.25 £967.50 Inc. VAT |
|
| AZMF-12-014UCB20PX-S0077 | 0511525612 | 14.0 cm3 / rev | £830.06 £996.07 Inc. VAT |
|
| AZMF-12-016UCB20PX-S0077 | 0511625617 | 16.0 cm3 / rev | £850.30 £1,020.36 Inc. VAT |
|
| AZMF-10-016USA20ML | 0511645601 | 16.0 cm3 / rev | £909.85 £1,091.82 Inc. VAT |
|
| AZMF-22-019UCB20PX-S0077 | 0511625615 | 19.0 cm3 / rev | £886.03 £1,063.24 Inc. VAT |
|
| AZMF-11-019USA20ML | 0511645603 | 19.0 cm3 / rev | £945.59 £1,134.71 Inc. VAT |
|
Bosch Rexroth Hydraulic External Gear Motors Type AZMF 8cc to 28cc
- Platform F
- Fixed displacement
- Size 8 … 28
- Continuous pressure up to 250 bar
- Maximum start-up pressure up to 280 bar
Features:
- Consistently high quality due to high-volume series production
- Long service life
- Wide speed range
- Slide bearings for high loading
- Optional reversible version for 2- and 4-quadrant operation
- Numerous configuration variants available
- Output shafts according to ISO or SAE and customer-specific solutions
- Line connections: Connection flanges or screw-in threads
- High pressures though small installation space and low weight
- Wide viscosity and temperature range
