Hengst Filter Elements Type 2

Hengst Filter Elements Type 2

The Filter Element is the central component in a filter, where the actual filtration takes place. The key filter parameters such as retention capacity, dirt holding capacity and pressure loss are determined by the Filter Element and the filter media used.

Hengst - Formerly Bosch Rexroth Filtration

Print page

Products
Downloads
Description
Part Number Material Number Nominal Size Filtration Rating Filter Media Pressure Seals Price Add to Parts List
2.0005 G100-A00-0-M 2.0005G100-A00-0-M R928018921 5 100um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £57.67
£69.20 Inc. VAT
2.0005 G25-A00-0-M 2.0005G25-A00-0-M R928006104 5 25um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £67.65
£81.18 Inc. VAT
2.0005 H3XL-A00-0-M 2.0005H3XL-A00-0-M R928006105 5 3um Glass fiber material, non-reusable 30 bar NBR £69.96
£83.95 Inc. VAT
2.0005 H10XL-A00-0-M 2.0005H10XL-A00-0-M R928006107 5 10um Glass fiber material, non-reusable 30 bar NBR £63.83
£76.60 Inc. VAT
2.0008 H20XL-A00-0-M 2.0008H20XL-A00-0-M R928006162 8 20um Glass fiber material, non-reusable 30 bar NBR £72.42
£86.90 Inc. VAT
2.0008 H10XL-A00-0-M 2.0008H10XL-A00-0-M R928006161 8 10um Glass fiber material, non-reusable 30 bar NBR £72.42
£86.90 Inc. VAT
2.0008 G60-A00-0-M 2.0008G60-A00-0-M R928018923 8 60um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £67.65
£81.18 Inc. VAT
2.0008 H6XL-A00-0-M 2.0008H6XL-A00-0-M R928006160 8 6um Glass fiber material, non-reusable 30 bar NBR £77.33
£92.80 Inc. VAT
2.0013 G100-A00-0-M 2.0013G100-A00-0-M R928018927 13 100um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £76.52
£91.82 Inc. VAT
2.0013 G25-A00-0-M 2.0013G25-A00-0-M R928006212 13 25um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £134.19
£161.03 Inc. VAT
2.0013 H6XL-A00-0-M 2.0013H6XL-A00-0-M R928006214 13 6um Glass fiber material, non-reusable 30 bar NBR £99.43
£119.32 Inc. VAT
2.0013 H20XL-A00-0-M 2.0013H20XL-A00-0-M R928006216 13 20um Glass fiber material, non-reusable 30 bar NBR £93.29
£111.95 Inc. VAT
2.0013 H10XL-A00-0-M 2.0013H10XL-A00-0-M R928006215 13 10um Glass fiber material, non-reusable 30 bar NBR £93.29
£111.95 Inc. VAT
2.0015 H10XL-A00-0-M 2.0015H10XL-A00-0-M R928006269 15 10um Glass fiber material, non-reusable 30 bar NBR £94.53
£113.44 Inc. VAT
2.0018 H10XL-A00-0-M 2.0018H10XL-A00-0-M R928006323 18 10um Glass fiber material, non-reusable 30 bar NBR £96.97
£116.36 Inc. VAT
2.18 G25-A00-0-M 2.18G25-A00-0-M R928022876 18 25um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £49.90
£59.88 Inc. VAT
2.0020 H6XL-A00-0-M 2.0020H6XL-A00-0-M R928006376 20 6um Glass fiber material, non-reusable 30 bar NBR £153.43
£184.12 Inc. VAT
2.0020 H10XL-A00-0-M 2.0020H10XL-A00-0-M R928006377 20 10um Glass fiber material, non-reusable 30 bar NBR £142.41
£170.89 Inc. VAT
2.0020 G25-A00-0-M 2.0020G25-A00-0-M R928006374 20 25um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £169.65
£203.58 Inc. VAT
2.0030 H6XL-A00-0-M 2.0030H6XL-A00-0-M R928006430 30 6um Glass fiber material, non-reusable 30 bar NBR £175.52
£210.62 Inc. VAT
2.0030 H20XL-A00-0-M 2.0030H20XL-A00-0-M R928006432 30 20um Glass fiber material, non-reusable 30 bar NBR £166.95
£200.34 Inc. VAT
2.0030 H10XL-A00-0-M 2.0030H10XL-A00-0-M R928006431 30 10um Glass fiber material, non-reusable 30 bar NBR £166.95
£200.34 Inc. VAT
2.0030 G40-A00-0-M 2.0030G40-A00-0-M R928018931 30 40um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £205.14
£246.17 Inc. VAT
2.0040 H6XL-B00-0-M 2.0040H6XL-B00-0-M R928006655 40 6um Glass fiber material, non-reusable 330 bar NBR £112.84
£135.41 Inc. VAT
2.0040 H3XL-B00-0-M 2.0040H3XL-B00-0-M R928006654 40 3um Glass fiber material, non-reusable 330 bar NBR £115.28
£138.34 Inc. VAT
2.0040 H10XL-A00-0-M 2.0040H10XL-A00-0-M R928006647 40 10um Glass fiber material, non-reusable 30 bar NBR £63.83
£76.60 Inc. VAT
2.0040 H6XL-A00-0-M 2.0040H6XL-A00-0-M R928006646 40 6um Glass fiber material, non-reusable 30 bar NBR £67.52
£81.02 Inc. VAT
2.0040 H3XL-A00-0-M 2.0040H3XL-A00-0-M R928006645 40 3um Glass fiber material, non-reusable 30 bar NBR £69.96
£83.95 Inc. VAT
2.0130 H10XL-B00-0-M 2.0130H10XL-B00-0-M R928022312 40 10um Glass fiber material, non-reusable 330 bar NBR £178.03
£213.64 Inc. VAT
2.0040 H10XL-B00-0-M 2.0040H10XL-B00-0-M R928006656 40 10um Glass fiber material, non-reusable 330 bar NBR £109.15
£130.98 Inc. VAT
2.0045 H20XL-A00-0-M 2.0045H20XL-A00-0-M R928006486 45 20um Glass fiber material, non-reusable 30 bar NBR £218.49
£262.19 Inc. VAT
2.0045 G25-A00-0-M 2.0045G25-A00-0-M R928006482 45 25um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £357.06
£428.47 Inc. VAT
2.0045 G40-A00-0-M 2.0045G40-A00-0-M R928018934 45 40um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £306.04
£367.25 Inc. VAT
2.0045 H6XL-A00-0-M 2.0045H6XL-A00-0-M R928006484 45 6um Glass fiber material, non-reusable 30 bar NBR £238.12
£285.74 Inc. VAT
2.0063 H6XL-A00-0-M 2.0063H6XL-A00-0-M R928006700 63 6um Glass fiber material, non-reusable 30 bar NBR £77.33
£92.80 Inc. VAT
2.0063 H3XL-A00-0-M 2.0063H3XL-A00-0-M R928006699 63 3um Glass fiber material, non-reusable 30 bar NBR £83.47
£100.16 Inc. VAT
2.0063 H10XL-B00-0-M 2.0063H10XL-B00-0-M R928006710 63 10um Glass fiber material, non-reusable 330 bar NBR £124.88
£149.86 Inc. VAT
2.0063 H6XL-B00-0-M 2.0063H6XL-B00-0-M R928006709 63 6um Glass fiber material, non-reusable 330 bar NBR £129.81
£155.77 Inc. VAT
2.0063 H3XL-B00-0-M 2.0063H3XL-B00-0-M R928006708 63 6um Glass fiber material, non-reusable 330 bar NBR £135.93
£163.12 Inc. VAT
2.0063 H20XL-A00-0-M 2.0063H20XL-A00-0-M R928006702 63 20um Glass fiber material, non-reusable 30 bar NBR £72.42
£86.90 Inc. VAT
2.0063 H10XL-A00-0-M 2.0063H10XL-A00-0-M R928006701 63 10um Glass fiber material, non-reusable 30 bar NBR £72.42
£86.90 Inc. VAT
2.90 H10XL-C00-0-M 2.90H10XL-C00-0-M R928025500 90 10um Glass fiber material, non-reusable 160 bar NBR £190.60
£228.72 Inc. VAT
2.90 H10XL-A00-0-M 2.90H10XL-A00-0-M R928019031 90 10um Glass fiber material, non-reusable 30 bar NBR £74.89
£89.87 Inc. VAT
2.90 G25-A00-0-M 2.90G25-A00-0-M R928046064 90 25um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £113.09
£135.71 Inc. VAT
2.90 G40-A00-0-M 2.90G40-A00-0-M R928019926 90 40um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £93.13
£111.76 Inc. VAT
2.0100 H10XL-B00-0-M 2.0100H10XL-B00-0-M R928006764 100 100um Glass fiber material, non-reusable 330 bar NBR £161.30
£193.56 Inc. VAT
2.0100 H6XL-B00-0-M 2.0100H6XL-B00-0-M R928006763 100 6um Glass fiber material, non-reusable 330 bar NBR £167.44
£200.93 Inc. VAT
2.0100 H3XL-B00-0-M 2.0100H3XL-B00-0-M R928006762 100 3um Glass fiber material, non-reusable 330 bar NBR £173.56
£208.27 Inc. VAT
2.0100 H10XL-A00-0-M 2.0100H10XL-A00-0-M R928006755 100 10um Glass fiber material, non-reusable 30 bar NBR £93.29
£111.95 Inc. VAT
2.0100 H6XL-A00-0-M 2.0100H6XL-A00-0-M R928006754 100 6um Glass fiber material, non-reusable 30 bar NBR £99.43
£119.32 Inc. VAT
2.0100 H3XL-A00-0-M 2.0100H3XL-A00-0-M R928006753 100 3um Glass fiber material, non-reusable 30 bar NBR £105.56
£126.67 Inc. VAT
2.0130 H3XL-B00-0-M 2.0130H3XL-B00-0-M R928022310 130 3um Glass fiber material, non-reusable 330 bar NBR £193.97
£232.76 Inc. VAT
2.0130 H10XL-A00-0-M 2.0130H10XL-A00-0-M R928022276 130 10um Glass fiber material, non-reusable 30 bar NBR £94.53
£113.44 Inc. VAT
2.0130 H6XL-A00-0-M 2.0130H6XL-A00-0-M R928022275 130 6um Glass fiber material, non-reusable 30 bar NBR £104.33
£125.20 Inc. VAT
2.0130 H3XL-A00-0-M 2.0130H3XL-A00-0-M R928022274 130 3um Glass fiber material, non-reusable 30 bar NBR £110.46
£132.55 Inc. VAT
2.140 G25-A00-0-M 2.140G25-A00-0-M R928022606 140 25um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £153.02
£183.62 Inc. VAT
2.0150 H3XL-A00-0-M 2.0150H3XL-A00-0-M R928022283 150 3um Glass fiber material, non-reusable 30 bar NBR £115.37
£138.44 Inc. VAT
2.0150 H10XL-A00-0-M 2.0150H10XL-A00-0-M R928022285 150 10um Glass fiber material, non-reusable 30 bar NBR £96.97
£116.36 Inc. VAT
2.0150 H6XL-A00-0-M 2.0150H6XL-A00-0-M R928022284 150 6um Glass fiber material, non-reusable 30 bar NBR £108.00
£129.60 Inc. VAT
2.0160 H10XL-A00-0-M 2.0160H10XL-A00-0-M R928006809 160 10um Glass fiber material, non-reusable 30 bar NBR £142.41
£170.89 Inc. VAT
2.0160 H10XL-B00-0-M 2.0160H10XL-B00-0-M R928006818 160 10um Glass fiber material, non-reusable 330 bar NBR £265.26
£318.31 Inc. VAT
2.0160 H6XL-A00-0-M 2.0160H6XL-A00-0-M R928006808 160 6um Glass fiber material, non-reusable 30 bar NBR £153.43
£184.12 Inc. VAT
2.0160 H6XL-B00-0-M 2.0160H6XL-B00-0-M R928006817 160 6um Glass fiber material, non-reusable 330 bar NBR £276.28
£331.54 Inc. VAT
2.0160 H3XL-A00-0-M 2.0160H3XL-A00-0-M R928006807 160 3um Glass fiber material, non-reusable 30 bar NBR £160.78
£192.94 Inc. VAT
2.0160 H3XL-B00-0-M 2.0160H3XL-B00-0-M R928006816 160 3um Glass fiber material, non-reusable 330 bar NBR £283.67
£340.40 Inc. VAT
2.0250 H10XL-A00-0-M 2.0250H10XL-A00-0-M R928006863 250 10um Glass fiber material, non-reusable 30 bar NBR £166.95
£200.34 Inc. VAT
2.0250 H10XL-B00-0-M 2.0250H10XL-B00-0-M R928006872 250 10um Glass fiber material, non-reusable 330 bar NBR £314.86
£377.83 Inc. VAT
2.0250 H6XL-A00-0-M 2.0250H6XL-A00-0-M R928006862 250 6um Glass fiber material, non-reusable 30 bar NBR £175.52
£210.62 Inc. VAT
2.0250 H6XL-B00-0-M 2.0250H6XL-B00-0-M R928006871 250 6um Glass fiber material, non-reusable 330 bar NBR £323.43
£388.12 Inc. VAT
2.0250 H3XL-A00-0-M 2.0250H3XL-A00-0-M R928006861 250 3um Glass fiber material, non-reusable 30 bar NBR £181.66
£217.99 Inc. VAT
2.0250 H3XL-B00-0-M 2.0250H3XL-B00-0-M R928006870 250 3um Glass fiber material, non-reusable 330 bar NBR £329.57
£395.48 Inc. VAT
2.0400 H3XL-B00-0-M 2.0400H3XL-B00-0-M R928006924 400 3um Glass fiber material, non-reusable 330 bar NBR £480.73
£576.88 Inc. VAT
2.0400 H20XL-A00-0-M 2.0400H20XL-A00-0-M R928006918 400 20um Glass fiber material, non-reusable 30 bar NBR £218.49
£262.19 Inc. VAT
2.0400 H10XL-A00-0-M 2.0400H10XL-A00-0-M R928006917 400 10um Glass fiber material, non-reusable 30 bar NBR £86.55
£103.86 Inc. VAT
2.0400 H10XL-B00-0-M 2.0400H10XL-B00-0-M R928006926 400 10um Glass fiber material, non-reusable 330 bar NBR £445.15
£534.18 Inc. VAT
2.0400 H6XL-A00-0-M 2.0400H6XL-A00-0-M R928006916 400 6um Glass fiber material, non-reusable 30 bar NBR £238.12
£285.74 Inc. VAT
2.0400 H6XL-B00-0-M 2.0400H6XL-B00-0-M R928006925 400 6um Glass fiber material, non-reusable 330 bar NBR £464.77
£557.72 Inc. VAT
2.0400 H3XL-A00-0-M 2.0400H3XL-A00-0-M R928006915 400 3um Glass fiber material, non-reusable 30 bar NBR £254.09
£304.91 Inc. VAT
2.0630 H10XL-A00-0-M 2.0630H10XL-A00-0-M R928006971 630 10um Glass fiber material, non-reusable 30 bar NBR £358.43
£430.12 Inc. VAT
2.0630 H10XL-B00-0-M 2.0630H10XL-B00-0-M R928006980 630 10um Glass fiber material, non-reusable 330 bar NBR £639.94
£767.93 Inc. VAT
2.0630 H6XL-A00-0-M 2.0630H6XL-A00-0-M R928006970 630 6um Glass fiber material, non-reusable 30 bar NBR £376.83
£452.20 Inc. VAT
2.0630 H6XL-B00-0-M 2.0630H6XL-B00-0-M R928006979 630 6um Glass fiber material, non-reusable 330 bar NBR £658.34
£790.01 Inc. VAT
2.0630 H3XL-A00-0-M 2.0630H3XL-A00-0-M R928006969 630 3um Glass fiber material, non-reusable 30 bar NBR £419.80
£503.76 Inc. VAT
2.0630 H3XL-B00-0-M 2.0630H3XL-B00-0-M R928006978 630 3um Glass fiber material, non-reusable 330 bar NBR £701.31
£841.57 Inc. VAT
2.1000 H6XL-A00-0-M 2.1000H6XL-A00-0-M R928007024 1000 6um Glass fiber material, non-reusable 30 bar NBR £433.28
£519.94 Inc. VAT
2.1000 H3XL-A00-0-M 2.1000H3XL-A00-0-M R928007023 1000 3um Glass fiber material, non-reusable 30 bar NBR £455.38
£546.46 Inc. VAT
2.1000 H10XL-B00-0-M 2.1000H10XL-B00-0-M R928007034 1000 10um Glass fiber material, non-reusable 30 bar NBR £825.43
£990.52 Inc. VAT
2.1000 H10XL-A00-0-M 2.1000H10XL-A00-0-M R928007025 1000 10um Glass fiber material, non-reusable 30 bar NBR £422.23
£506.68 Inc. VAT
2.0004 P10-A00-0-M 2.0004P10-A00-0-M R928007211 4 10um Filter paper, non-reusable 30 bar NBR £41.76
£50.11 Inc. VAT
2.0004 G100-A00-0-M 2.0004G100-A00-0-M R928018919 4 100um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £51.00
£61.20 Inc. VAT
2.0004 G40-A00-0-M 2.0004G40-A00-0-M R928018916 4 40um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £59.88
£71.86 Inc. VAT
2.0004 G25-A00-0-M 2.0004G25-A00-0-M R928006050 4 25um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £63.20
£75.84 Inc. VAT
2.0004 H6XL-A00-0-M 2.0004H6XL-A00-0-M R928006052 4 6um Glass fiber material, non-reusable 30 bar NBR £63.20
£75.84 Inc. VAT
2.0004 G25-AH0-0-V 2.0004G25-AH0-0-V R928007933 4 25um Stainless steel wire mesh, recyclable (cleanable) 30 bar FKM £83.49
£100.19 Inc. VAT
2.0004 H10XL-A00-0-V 2.0004H10XL-A00-0-V R928006080 4 10um Glass fiber material, non-reusable 30 bar FKM £77.63
£93.16 Inc. VAT
2.0004 G10-A00-0-M 2.0004G10-A00-0-M R928006049 4 10um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £77.63
£93.16 Inc. VAT
2.0004 H10XL-A00-0-M 2.0004H10XL-A00-0-M R928006053 4 10um Glass fiber material, non-reusable 30 bar NBR £59.35
£71.22 Inc. VAT
2.0004 G60-A00-0-M 2.0004G60-A00-0-M R928018917 4 60um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £55.44
£66.53 Inc. VAT
2.0004 G100-A00-0-V 2.0004G100-A00-0-V R928019553 4 100um Stainless steel wire mesh, recyclable (cleanable) 30 bar FKM £59.35
£71.22 Inc. VAT
2.10 P10-A00-0-M 2.10P10-A00-0-M R928019065 10 10um Filter paper, non-reusable 30 bar NBR £23.85
£28.62 Inc. VAT
2.10 G25-A00-0-M 2.10G25-A00-0-M R928019063 10 25um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £49.90
£59.88 Inc. VAT
2.225 G25-A00-0-M 2.225G25-A00-0-M R928023910 225 25um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £205.14
£246.17 Inc. VAT
2.225 P25-A00-0-M 2.225P25-A00-0-M R928022710 225 25um Filter paper, non-reusable 30 bar NBR £83.51
£100.21 Inc. VAT
2.32 G25-A00-0-M 2.32G25-A00-0-M R928019473 32 25um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £63.20
£75.84 Inc. VAT
2.32 P10-A00-0-M 2.32P10-A00-0-M R928019137 32 10um Filter paper, non-reusable 30 bar NBR £45.32
£54.38 Inc. VAT
2.32 H10XL-C00-0-M 2.32H10XL-C00-0-M R928019712 32 10um Glass fiber material, non-reusable 160 bar NBR £94.61
£113.53 Inc. VAT
2.32 G100-A00-0-M 2.32G100-A00-0-M R928022695 32 100um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £51.00
£61.20 Inc. VAT
2.360 G25-C00-0-M 2.360G25-C00-0-M R928045963 360 25um Stainless steel wire mesh, recyclable (cleanable) 160 bar NBR £527.46
£632.95 Inc. VAT
2.56 G40-A00-0-M 2.56G40-A00-0-M R928022605 56 40um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £77.63
£93.16 Inc. VAT
2.56 H10XL-A00-0-M 2.56H10XL-A00-0-M R928023991 56 10um Glass fiber material, non-reusable 30 bar NBR £67.52
£81.02 Inc. VAT
2.56 G25-A00-0-M 2.56G25-A00-0-M R928018942 56 25um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £86.49
£103.79 Inc. VAT
2.56 G100-A00-0-M 2.56G100-A00-0-M R928025229 56 100um Stainless steel wire mesh, recyclable (cleanable) 30 bar NBR £63.20
£75.84 Inc. VAT
RE 51517 2023-02

Hengst Filter Elements Type 2

  • Nominal size 0040 … 1000
  • Differential pressure 30, 160 or 330 bar
  • Filter rating 1 μm

Features:

  • Filter media made of glass fiber material (optionally water absorbing), filter paper, wire mesh, non-woven material and non-woven metal fiber for various fields of application. Information on filter material configuration is available in RE 51548
  • Cleanable wire mesh filter media
  • Attainable oil cleanliness class of up to ISO 10/6/4 (ISO 4406)
  • High dirt holding capacity and filtration performance due to multi-layer glass fiber technology and simultaneous low initial differential pressure
  • Extended product range for non-mineral oil-based fluids
  • Filter elements with high differential pressure stability
