Hydac "DN" Type Pressure elements DIN

Type "DN" elements are used in pressure filters in accordance with DIN 24550, e.g. in the series DFN, FLN, FLND, FMND, LFN, LFNF.

  • Filter rating: 3 to 200 µm
  • Filter materials: glass fibre, wire mesh
  • Absolute or nominal filtration, depending on the filter material
  • Permissible differential pressure: 30 to 160 bar
  • Without bypass valve

HYDAC "DN" Type Pressure Filter Elements, compliant with DIN 24550 and compatible with series such as DFN, FLN, and LFN, provide absolute or nominal filtration from 3 to 200 µm using high-performance glass fibre or wire mesh media, with differential pressure tolerance from 30 to 160 bar. Designed for use in demanding hydraulic systems up to 100 °C, they offer high dirt-holding capacity, efficiency, and fluid compatibility across a wide range of oils and fire-resistant fluids per ISO standards.

Print page

Description
Downloads
Hydac "DN" Type Pressure elements DIN

HYDAC "DN" Type Pressure elements DIN

  • Filter rating: 3 to 200 µm
  • Filter materials: glass fibre, wire mesh
  • Absolute or nominal filtration, depending on the filter material
  • Permissible differential pressure: 30 to 160 bar
  • Without bypass valve

"DN" Type Pressure filter elements in accordance with DIN 24550 are used in pressure filters, e.g. in the series DFN, FLN, FLND, FMND, LFN, LFNF

Features:

  • Operating temperature: up to 100°C
  • In accordance with DIN 24550
  • Compatible with all conventional operating media
  • High Dirt Holding Capacities
  • Great Cost to Value Ratio
  • High Efficiency Absolute Ratings

COMPATIBILITY WITH HYDRAULIC FLUIDS TO ISO 2943

  • Hydraulic oils H to HLPD DIN 51524
  • Lubrication oils DIN 51517, API, ACEA, DIN 51515, ISO 6743
  • Compressor oils DIN 51506
  • Biodegradable operating fluids VDMA 24568 HETG, HEES, HEPG
  • Fire-resistant fluids HFA, HFB, HFC and HFD

Operating fluids with high water content (> 50 % water content) on request

HYDAC "DN"Type pressure elements are validated and their quality is constantly monitored according to the following standards:

  • ISO 2941, ISO 2942, ISO 2943, ISO 3724, ISO 3968, ISO 11170, ISO 16889
