A10VER series 52 Size 18 to 45

Bosch Rexroth Hydraulic Variable Displacement Motors A10VER 18cc to 45cc

• Reversible axial piston motor for fan drives
• Sizes 18 to 45
• Nominal pressure 280 bar
• Maximum pressure 350 bar
• Open circuit

Features:

• Variable motor with axial piston rotary group in swashplate design for hydrostatic fan drives in open circuits
• The output speed is proportional to the inlet flow
• The output torque increases proportionally with the pressure difference between the high- and low-pressure sides and increasing displacement
• Specially developed for hydrostatic fan drives
• The A10VER variable motor is equipped with an over centre rotary group with a maximum displacement of +/-100% Vg max. This allows reversing operation without the need for costly additional components to reverse the air flow and to clean the cooler from contaminations which leads to fuel savings due to improved cooling performance.
• The energy efficiency of hydraulic fan drives is increased due to the elimination of external reversing valves.
• Stable bearing for long service life
• High maximum permissible output speed
• Favourable power-to-weight ratio – compact dimensions
• Low noise
