miniBOOSTER HC3-D

The HC3 – D is a variant of the HC3, with all ports in one end. The entire pattern is a miniBOOSTER design. It is a compact unit weighing only 1.75 kg.

Maximum outlet pressure is 800 bar in standard versions. An adjustment of the outlet pressure is carried out by varying the supplied pressure.

HC3 – D versions: 15 different intensification factors

P - IN: 20 – 207 bar

P - H: 800 bar maximum

P - RETURN: As low as possible (return pressure to tank)

P - OUTLET: PH = (PIN – PRETURN) x intensification factor

Mounting: Manifold system miniBOOSTER pattern

Weight:  1.75 kg.

Model versions:

A model = no dump valve

B model = with dump valve

G model = direct proportionally controlled

Material certificate 3.1 on request
