Minibooster HC6D2

The HC6D2 is a dual media unit which is capable of delivering up to 36.5 l/min flow on the high-pressure end. Like other miniBOOSTER models, the HC6D2 raises supplied pressure to a higher outlet pressure and automatically compensates for consumption of oil to maintain the high pressure.

Adjustment of the outlet pressure is carried out by varying the supplied pressure. Relative to its flow capability, the HC6D2 is a compact unit weighing 24 kg.

HC6D2 versions: 9 different intensification factors

P - IN: 20 – 207 bar

P - H: 800 bar maximum

P - RETURN: As low as possible (return pressure to tank)

P - OUTLET: PH = (PIN – PRETURN) x intensification factor

Drain connections: Max. 10 bar

Mounting: Inline tube

Weight: 24.0 kg.

Model version:

A model = no dump valve

Material certificate 3.1 on request
