Hydac Silencers SD...
Silencers SD...
- V = 0.5 ...5.5 l
- pmax = 330 bar
- Silencer for fluid noise damping
The HYDAC SD Silencer (0.5–5.5 L, up to 330 bar) effectively reduces fluid-borne noise in hydraulic systems using an expansion chamber with interference lines to dampen oscillations across a wide frequency range. Maintenance-free and compatible with various fluids, it’s ideal for use in vehicles, machine tools, ships, aircraft, and industrial systems. With a durable, welded or forged housing and no moving parts, it offers long-lasting noise reduction in even the most demanding environments.
Hydac Silencers SD...
- V = 0.5 ...5.5 l
- pmax = 330 bar
- Silencer for fluid noise damping
Applications:
Vehicles, machine tools, plastics machinery, aeroplanes, ships, hydraulic power stations and other systems with a large "surface" are all applications where the noise level can be reduced
General Function:
The HYDAC fluid SILENCER is based on the principle of an expansion chamber with interference line.
By reflecting the oscillations within the silencer the majority of the oscillations are dampened across a wide frequency spectrum
Design:
- The HYDAC SILENCER consists of a welded or forged external housing, an internal tube and two pipe connections on opposite sides
- The SILENCER has no moving parts and no gas charge and is therefore absolutely maintenance free
- The HYDAC SILENCER can be used for mineral oils, phosphate ester and water glycol
- A stainless steel model is available for other fluids
Special model:
SILENCERS can also be in the form of diaphragm or piston accumulators
Installation:
It is recommended that one connection side is joined via a flexible hose in order to reduce the transmission of mechanical vibrations. The installation position of the damper is optional, but the flow direction must be taken into account
