Hydac Accessories for Service Instruments HMG 500 / 3000

HYDAC Accessories for Service Instruments HMG 500 / 3000

• Case
• Power packs
• Connection adapters
• Connection cable
• Hydraulic adapter
• Rpm probe
• Sensor simulator

Sensors (accessories):

• Pressure transducer HDA 4748-H (with HSI sensor recognition)
• Temperature transmitter ETS 4548-H (with HSI sensor recognition)
• Flow rate transmitter EVS 31x0-H (with HSI sensor recognition)

Aluminium case
for HMG 30X0 and accessories
Part No.: 6042959

Bag with carrying strap
for HMG 30X0
Part No.: 909795

Power supply unit
for HMG 30X0, Spare Part
Part No.: 6054296

ZBE 31
Car charger for HMG 30X0
Part No.: 909739

ZBE 34
Adapter for HMG 30X0 for connecting HYDAC transmitters (4 .. 20 mA, 2 conductor) Male M12x1 to Binder series 714 M18 (electrical connection type "4")
Part No.: 3236597

ZBE 35
Adapter for HMG 30X0 for connecting HYDAC transmitters (4 .. 20 mA, 2 conductor) Male M12x1 to Male EN175301-803 (DIN 43650) (electrical connection type "5")
Part No.: 3236601

ZBE 36
Adapter for HMG 30X0 for connecting an AquaSensor AS 1000
Part No.: 909737

ZBE 38
Y adapter (black) for HMG 30X0 to double the number of input sockets
Part No.: 3224436

ZBE 41
Y adapter (yellow) for HMG 30X0 for connecting a ContaminationSensor CS 1000
Part No.: 910000

ZBE 3010
CAN adapter for HMG 3010 for connecting a CAN-Bus
Part No.: 921238

Connection cable
for HMG 30X0 - PC (USB), Spare Part
Part No.: 6040585

Hydraulic adapter kit for HMG

2 pieces each
- Adapter hose DN 2 -1620 / 1620 (400 mm and 1000 mm)
- Pressure gauge conn. 1620 / G1/4
- Adapter 1650 / 1620
- Bulkhead union 1620 / 1620
Part No.: 903083

HDS 1000 RPM probe
for HMG 3000 including reflective foil set
Part No.: 909436

HDS 1000 reflective foil set
Spare Part, Quantity: 25
Part No.: 904812

UVM 3000
Module for HMG 3000 for connecting different input signals
Part No.: 909752

Plastic case
for HMG 500/510 and accessories
Part No.: 6043006

Power supply (230 V AC)
for HMG 500/510
Part No.: 6043562

Connection cable
for HMG 510 - PC (USB),
Spare Part
Part No.: 6049553

ZBE 30-02 (5 pole)
Connection cable M12x1, 2 m male/female
Part No.: 6040851

ZBE 30-05 (5 pole)
Connection cable M12x1, 5 m male/female
Part No.: 6040852

SSH 1000
Sensor simulator to simulate 2 HSI sensors, ideal for training purposes
Part No.: 909414
