Hydac Electronic Temperature Switch ETS 3800 for Separate Temperature Probe with IO-Link Interface

The HYDAC ETS 3800 with IO-Link is a compact electronic temperature switch featuring a 4-digit LED display and designed for use with a separate temperature probe. With a measuring range of -30 to +150 °C and IO-Link V1.1 communication, it enables seamless integration into modern automation systems, offering advanced parameterization and real-time data exchange.

Key Features:

  • Measuring range1) -30 . +150°C (-22 . 302°F)
  • Display: 4-digit, LED, 7 segment, red, height of digits 7mm
  • Connection, separate temperature probe Female cable connection: M12x1, 4 pole

Depending on the temp' range of the connected temp' sensor the measurement range of the ETS 3800 may be reduced.

Print page

Description
Downloads
Hydac Electronic Temperature Switch ETS 3800 for Separate Temperature Probe with IO-Link Interface

HYDAC Electronic Temperature Switch ETS 3800 for Separate Temperature Probe with IO-Link Interface

  • Measuring range1) -30 .. +150 °C (-22 .. 302 °F)
  • Display: 4-digit, LED, 7 segment, red, height of digits 7 mm
  • Connection, separate temperature probe Female cable connection: M12x1, 4 pole

1) Depending on the temperature range of the connected temperature sensor, the measurement range of the ETS 3800 may be reduced.

Features:

  • IO-Link interface
  • 1 PNP transistor switching output
  • Additional signal output, can be configured as PNP transistor switching output or analogue output
  • 4-digit digital display
  • Optimum alignment of the display − can be rotated in two axes

General Function:

The ETS 3800 with IO-Link communication interface is a compact, electronic temperature switch with 4-digit display. The version for a separate temperature probe has a measuring range of -30 ... +150 °C and is used primarily with the TFP 100 temperature probe which was specially developed for tank installation.
Compared with the standard version, the IO-Link interface enables bidirectional communication between the device and the control. Parameterisation and cyclical transmission of process and service data is therefore possible. The temperature switch series ETS 3800 with communication interface IO-Link according to specification V1.1 was specially designed to connect sensors in automation systems. Typical fields of application are machine tools, handling and assembly automation, intralogistics or the packaging industry.
