Hydac Electronic Temperature Transmitter ETS 4100

The HYDAC ETS 4100 is a robust electronic temperature transmitter designed for industrial and hydraulic applications, offering precise measurement in the -25 to +100 °C range. With analogue outputs (4–20 mA / 0–10 V), high pressure resistance (up to 600 bar), and strong EMC performance, it ensures reliable operation even in demanding environments.

Key Features:

  • Measuring range: -25 .. +100 °C
  • Probe length: 6; 50; 100; 250; 350 mm
  • Mechanical connection: G1/4 A DIN 3852
Print page

Description
Downloads
Hydac Electronic Temperature Transmitter ETS 4100

HYDAC Electronic Temperature Transmitter ETS 4100

  • Measuring range: -25 .. +100 °C
  • Probe length: 6; 50; 100; 250; 350 mm
  • Mechanical connection: G1/4 A DIN 3852

Features:

  • Accuracy ≤ ± 0.8 % FS
  • Ideal for industrial applications
  • Robust design
  • Excellent EMC characteristics
  • Excellent long term stability
  • Standard protection class IP 65 / IP 67

General Function:

The ETS 4100 is a robust electronic temperature transmitter which is particularly suited to measuring temperature in hydraulic applications in industry. The temperature sensor, based on a PT 1000 and corresponding evaluation electronics, is capable of measuring temperatures in the range -25 °C to +100 °C. The sensor has analogue output signals of 4 .. 20 mA and 0 ..10 V available as standard for integration into modern control systems. The pressure resistance up to 600 bar and excellent EMC characteristics make the ETS 4100 ideal for use in harsh conditions.
