Hydac Inline Filter LFR with Magnetic Core
The HYDAC Inline Filter LFR with Magnetic Core is built for efficient hydraulic filtration, handling flow rates up to 250 l/min and pressures up to 120 bar. Its top-removable element, integrated magnetic core, and clogging indicator help trap contaminants and ensure system reliability. With mounting holes for secure installation and optional bypass cracking pressure, it offers flexibility and long-term performance.
Key Features:
- Flow rates up to 250 l/min
- Pressure levels up to 120 bar
- Connections: G½ to G1½
Description
Downloads
HYDAC Inline Filter LFR with Magnetic Core
- Flow rates up to 250 l/min
- Pressure levels up to 120 bar
- Connections: G½ to G1½
- Installation sizes: 20, 45, 80, 150, 250
- Flow from inside to outside
Features:
- The filter housings are designed in accordance with international regulations
- They consist of a filter housing and a screw-on cover plate
- The element is top-removable
- Mounting holes in the housing
- Magnetic core built into cover plate
- Oil drain plug
- Type of clogging indicator VM (differential pressure measurement up to 210 bar operating pressure)
- Pressure setting of the clogging indicator 2 bar (others on request)
- Bypass cracking pressure (optional) 2.5 bar (others on request)
- Special models and accessories available on request
HYDAC filter elements are validated and their quality is constantly monitored according to the following standards:
- ISO 2941, ISO 2942, ISO 2943, ISO 3968, ISO 11170, ISO 16889
Filter elements are available with the following pressure stability values:
- Glass fibre (ULP): 6 bar
- Glass fibre with pre-filter (UHC): 6 bar
- Wire mesh (WR): 6 bar
- Other filtration ratings on request
