Hydac Reversible Inline Filter AFLD in Accordance with API 614 Standard
HYDAC AFLD Reversible Inline Filters are built to meet API 614 standards for lube oil systems and other demanding applications. Designed for flow rates up to 1700 l/min and pressures up to 40 bar, they offer reliable operation with ANSI flanged connections and easy changeover via an integrated transfer valve.
Key Features:
- Flow rates up to 1700 l/min
- Pressure levels up to 40 bar
- API 614-Compliant - ideal for lube oil and critical systems
Description
Downloads
HYDAC Reversible Inline Filter AFLD in Accordance with API 614 Standard
- Flow rates up to 1700 l/min
- Pressure levels up to 40 bar
- Connections: DN 25 to DN 150 in accordance with ANSI
- Installation sizes: 122, 123, 232, 233, 332, 333, 542, 543, 882, 883, 1402, 1403, 2702, 2703
Features:
- Filter series designed to meet the requirements of API 614 for lube oil and other applications
- Models are available in carbon and stainless steel versions
- Transfer valve internal components of stainless steel
- ANSI flange connections standard
- Inlet and outlet connections are located on the same side of the transfer valve
- Transfer valve and pressure equalization line allow easy changeover between filter housings without costly system shutdown
- Air bleed line available
- ASME coded with U-stamp available
- 2.2 material certificate standard
- 3.1 B material certificate optional
