Hydac Inline Filter MFX

The HYDAC MFX Inline Filter offers compact and robust filtration for systems operating up to 50 bar and 130 l/min. With multiple clogging indicator options and a standard bypass valve, it ensures reliable protection in return and pressure line applications.

Key Features:

  • Flow Capacity: Up to 130 l/min
  • Pressure Rating: Up to 50 bar
  • Bypass Valve: Standard, 3.5 bar cracking pressure (optional 1.7 bar)
Print page

Description
Downloads
Hydac Inline Filter MFX

HYDAC Inline Filter MFX

  • Flow rates up to 130 l/min
  • Pressure levels up to 50 bar
  • Connections: G¾ to M33x2
  • Installation sizes: 100, 200

Features:

  • The filter housings are designed in accordance with international regulations
  • They consist of a filter head and a screw-in filter bowl
  • Usually 4 possible positions for a clogging indicator as standard
  • Type of clogging indicator VM (Diff. pressure indicator up to 210 bar operating pressure) VL (Diff. pressure indicator up to 50 bar operating pressure)
  • Setting pressure of the clogging indicator Standard 2.5 bar, optional 1 bar (others on request)
  • Standard equipment with bypass valve
  • Bypass cracking pressure Standard 3.5 bar, optional 1.7 bar (others on request)
  • Compatibility with hydraulic fluids ISO 2943
  • Special models and accessories available on request
  • Certificates and approvals available on request

HYDAC filter elements are validated and their quality is constantly monitored according to the following standards:

  • ISO 2941, ISO 2942, ISO 2943, ISO 3724, ISO 3968, ISO 16889

Filter elements are available with the following pressure stability values:

  • Betamicron® (BN4HC): 10 bar
  • ECOmicron® (ECON2): 10 bar
  • Mobilemicron (MM): 10 bar
