Hydraulic Clamping Pump
ROEMHELD D8.800 Manually Operated Hydraulic Pump with Foot Lever, Base and Pressure Gauge
- Displacement per stroke: 2 .. 8 cm³
- Oil volume: 300 .. 970 cm³
- Usable oil volume: 150 .. 750 cm³
- Hydraulic connection: G 1/4
- Pump supplied is filled with oil
Type with foot lever, base and pressure gauge In connection with our clamping elements, workpieces can be clamped economically with this clamping pump. Furthermore, this pump can be used for lifting loads, adjusting and clamping tables, as well as for other operating processes.
Description
Downloads
Hydraulic Clamping Pump - ROEMHELD D8.800
- Displacement per stroke: 2 .. 8 cm³
- Oil volume: 300 .. 970 cm³
- Usable oil volume: 150 .. 750 cm³
- Hydraulic connection: G 1/4
- Pump supplied is filled with oil
Advantages:
- Choice of hand or foot operation
- Pumping and releasing with the same lever
- Continuously adjustable pressure relief valve
- Metallic seal on pump piston, thereby nearly wear-free
- Compact, self-contained design
Description:
Type with foot lever, base and pressure gauge In connection with our clamping elements, workpieces can be clamped economically with this clamping pump. Furthermore, this pump can be used for lifting loads, adjusting and clamping tables, as well as for other operating processes.
