SPEEDY Easy Click
The new SPEEDY easy click is a mechanical fast closing clamp that needs no energy supply to engage and hold immediately
Description
Downloads
SPEEDY Easy Click - Snaps in even without energy input
- push-in clamping process
- 85 mm in diameter and only 19 mm high
- 5 kN clamping force - 10 kN holding force
- release with 3 - 8 bar of air pressure
- release time 0.1 sec
Click - and holds:
The new Roemheld SPEEDY easy click is a mechanical fast closing clamp that needs no energy supply to engage and hold immediately
- You require a supply of compressed air at 3-8 bar to release
- SPEEDY easy click is used in cutting and non-cutting multi-axis machining
- The short clamping time allows it to be used as a construction element in production lines
- A particularly compact design allows narrow spacings, retractable nipples only 12 mm long and short extraction distances
- Oil-free applications, e.g. in the foodstuff industry, medical or chemical sectors, extend the field of use
