Directional Spool Valve, Pilot Operated with Hydraulic-hydraulic Actuation

WPH, WHH, WMMH, WMDH, WMDAH, WMRH and WMUH Sizes 10 to 32

Directional spool valve, pilot operated with hydraulic-hydraulic actuation for sub plate mounting

  • Sizes 10 to 32
  • Component series 4X; 6X; 7X
  • Maximum operating pressure 350 bar [5076 psi]
  • Maximum flow 1100 l/min [290 US gpm]

Description
Downloads

Bosch Rexroth Directional Spool Valve, Pilot Operated with Hydraulic-hydraulic Actuation

  • Sizes 10 to 32
  • Component series 4X; 6X; 7X
  • Maximum operating pressure 350 bar [5076 psi]
  • Maximum flow 1100 l/min [290 US gpm]

Features:

  • 7 types of actuation:
  • -Pneumatic-hydraulic (type WPH)
  • -Hydraulic-hydraulic (type WHH)
  • -Hand lever (type WMMH)
  • -Rotary knob (type WMDH)
  • -Rotary knob, lockable (type WMDAH)
  • -Roller plunger (type WMRH)
  • -Roller plunger, rotated 90° (type WMUH)
  • For sub plate mounting
  • Porting pattern to ISO 4401 and NFPA T3.5.1 R2-2002
  • Sub plates according to data sheets RE 45054 to
  • RE 45060 (separate order), see page 30
  • Spring centring, spring end position or hydraulic end position
  • Manual override, optional
  • Switching time adjustment, optional
  • Pre-load valve in channel P of the main valve, optional
  • Stroke adjustment of main spool, optional
  • Stroke adjustment and/or end position check, optional
  • Inductive position switches and proximity sensors
