Carr Lane Index Plungers

Index plungers are heavy-duty assemblies featuring a retractable, spring-loaded plunger and a corresponding locating bushing (sold separately). Tapered Index Plungers have a 15° taper on the plunger tip that matches the taper in the bushing, facilitating easier alignment and preventing binding during retraction. A straight plunger option is also available for slightly better positional accuracy. The plunger is fully retracted by a rotary-cam action when the handle is rotated 180°, with hardened steel cam surfaces for durability. The standard-mount configuration shown here includes a whistle notch on the Index Plunger to align with a setscrew. This configuration comes in three sizes, offering both inch and metric plunger diameters.

  • Rotary Cam with Standard or Flange mount
  • Available with Blank Machinable End
  • Choice of 3 Plunger diameters
  • Ground or Unground
  • Tapered index plungers

Products
Downloads
Description
Part Number Material Number Unground Tapered or Straight Mount Plunger or Bushing Plunger Diameter Price Add to Parts List
CL-22127-SIPB CL-22127-SIPB Unground Straight Flange Bushing 3/4 £22.87
£27.44 Inc. VAT
CL-22131-TIPB CL-22131-TIPB Unground Tapered Flange Bushing 3/4 £23.95
£28.74 Inc. VAT
CL-22226-SIPB CL-22226-SIPB Unground Straight Standard Bushing 1 £30.72
£36.86 Inc. VAT
CL-22026-SIPB CL-22026-SIPB Unground Straight Standard Bushing 1/2 £19.72
£23.66 Inc. VAT
CL-22130-TIPB CL-22130-TIPB Unground Tapered Standard Bushing 3/4 £22.34
£26.81 Inc. VAT
CL-22204-SIP CL-22204-SIP Unground Straight Standard Plunger 1 £260.44
£312.53 Inc. VAT
CL-22004-SIP CL-22004-SIP Unground Straight Standard Plunger 1/2 £145.15
£174.18 Inc. VAT
CL-22116-TIP CL-22116-TIP Unground Tapered Standard Plunger 3/4 £219.02
£262.82 Inc. VAT
CL-22105-SIP CL-22105-SIP Unground Straight Flange Plunger 3/4 £219.29
£263.15 Inc. VAT
CL-22117-TIP CL-22117-TIP Unground Tapered Flange Plunger 3/4 £234.56
£281.47 Inc. VAT
CL-22212-TIP CL-22212-TIP Unground Tapered Blank Machinable End Plunger 1 £216.17
£259.40 Inc. VAT
CL-22112-TIP CL-22112-TIP Unground Tapered Blank Machinable End Plunger 3/4 £166.74
£200.09 Inc. VAT
CL-22027-SIPB CL-22027-SIPB Unground Straight Flange Bushing 1/2 £21.36
£25.63 Inc. VAT
CL-22031-TIPB CL-22031-TIPB Unground Tapered Flange Bushing 1/2 £21.73
£26.08 Inc. VAT
CL-22126-SIPB CL-22126-SIPB Unground Straight Standard Bushing 3/4 £21.49
£25.79 Inc. VAT
CL-22230-TIPB CL-22230-TIPB Unground Tapered Standard Bushing 1 On Enquiry
CL-22030-TIPB CL-22030-TIPB Unground Tapered Standard Bushing 1/2 £21.60
£25.92 Inc. VAT
CL-22017-TIP CL-22017-TIP Unground Tapered Flange Plunger 1/2 £165.71
£198.85 Inc. VAT
CL-22104-SIP CL-22104-SIP Unground Straight Standard Plunger 3/4 £204.78
£245.74 Inc. VAT
CL-22216-TIP CL-22216-TIP Unground Tapered Standard Plunger 1 £291.43
£349.72 Inc. VAT
CL-22016-TIP CL-22016-TIP Unground Tapered Standard Plunger 1/2 £262.81
£315.37 Inc. VAT
CL-22005-SIP CL-22005-SIP Unground Straight Flange Plunger 1/2 £150.49
£180.59 Inc. VAT
CL-22012-TIP CL-22012-TIP Unground Tapered Blank Machinable End Plunger 1/2 £132.88
£159.46 Inc. VAT
CL-22102-SIP CL-22102-SIP Ground Straight Blank Machinable End Plunger 3/4 £159.46
£191.35 Inc. VAT
CL-22002-SIP CL-22002-SIP Ground Straight Blank Machinable End Plunger 1/2 £134.82
£161.78 Inc. VAT
CL-22129-SIPB CL-22129-SIPB Ground Straight Flange Bushing 3/4 £23.45
£28.14 Inc. VAT
CL-22133-TIPB CL-22133-TIPB Ground Tapered Flange Bushing 3/4 £24.79
£29.75 Inc. VAT
CL-22228-SIPB CL-22228-SIPB Ground Straight Standard Bushing 1 £30.26
£36.31 Inc. VAT
CL-22028-SIPB CL-22028-SIPB Ground Straight Standard Bushing 1/2 £21.22
£25.46 Inc. VAT
CL-22132-TIPB CL-22132-TIPB Ground Tapered Standard Bushing 3/4 £23.48
£28.18 Inc. VAT
CL-22214-TIP CL-22214-TIP Ground Tapered Blank Machinable End Plunger 1 £223.66
£268.39 Inc. VAT
CL-22107-SIP CL-22107-SIP Ground Straight Flange Plunger 3/4 £223.78
£268.54 Inc. VAT
CL-22119-TIP CL-22119-TIP Ground Tapered Flange Plunger 3/4 £239.35
£287.22 Inc. VAT
CL-22206-SIP CL-22206-SIP Ground Straight Standard Plunger 1 £266.23
£319.48 Inc. VAT
CL-22006-SIP CL-22006-SIP Ground Straight Standard Plunger 1/2 £148.58
£178.30 Inc. VAT
CL-22118-TIP CL-22118-TIP Ground Tapered Standard Plunger 3/4 £225.64
£270.77 Inc. VAT
CL-22114-TIP CL-22114-TIP Ground Tapered Blank Machinable End Plunger 3/4 £172.80
£207.36 Inc. VAT
CL-22029-SIPB CL-22029-SIPB Ground Straight Flange Bushing 1/2 £23.17
£27.80 Inc. VAT
CL-22033-TIPB CL-22033-TIPB Ground Tapered Flange Bushing 1/2 £23.57
£28.28 Inc. VAT
CL-22128-SIPB CL-22128-SIPB Ground Straight Standard Bushing 3/4 £23.09
£27.71 Inc. VAT
CL-22232-TIPB CL-22232-TIPB Ground Tapered Standard Bushing 1 £33.12
£39.74 Inc. VAT
CL-22032-TIPB CL-22032-TIPB Ground Tapered Standard Bushing 1/2 £23.46
£28.15 Inc. VAT
CL-22202-SIP CL-22202-SIP Ground Straight Blank Machinable End Plunger 1 £203.14
£243.77 Inc. VAT
CL-22014-TIP CL-22014-TIP Ground Tapered Blank Machinable End Plunger 1/2 £140.00
£168.00 Inc. VAT
CL-22007-SIP CL-22007-SIP Ground Straight Flange Plunger 1/2 £154.25
£185.10 Inc. VAT
CL-22019-TIP CL-22019-TIP Ground Tapered Flange Plunger 1/2 £168.54
£202.25 Inc. VAT
CL-22106-SIP CL-22106-SIP Ground Straight Standard Plunger 3/4 £210.96
£253.15 Inc. VAT
CL-22218-TIP CL-22218-TIP Ground Tapered Standard Plunger 1 £298.75
£358.50 Inc. VAT
CL-22018-TIP CL-22018-TIP Ground Tapered Standard Plunger 1/2 £165.62
£198.74 Inc. VAT

Carr Lane Index Plungers

  • Tapered index plungers
  • Rotary Cam with Standard or Flange mount
  • Available with Blank Machinable End
  • Choice of 3 Plunger diameters
  • Ground or Unground

Index plungers are heavy-duty assemblies featuring a retractable, spring-loaded plunger and a corresponding locating bushing (sold separately). Tapered Index Plungers have a 15° taper on the plunger tip that matches the taper in the bushing, facilitating easier alignment and preventing binding during retraction. A straight plunger option is also available for slightly better positional accuracy. The plunger is fully retracted by a rotary-cam action when the handle is rotated 180°, with hardened steel cam surfaces for durability. The standard-mount configuration shown here includes a whistle notch on the Index Plunger to align with a setscrew. This configuration comes in three sizes, offering both inch and metric plunger diameters.

Standard Mount

  • The standard-mount configuration shown has a precision ground body with a whistle notch for orientation with a setscrew (also available with a slightly oversize unground body to allow custom grinding to size).

Flange Mount

  • The flange-mount configuration shown has a precision ground body with a flange used for orientation by fastening with two socket-head cap screws (also available with a slightly oversize unground body to allow custom grinding to size). Flange mounting is designed for installations where a cross hole for a set screw is not practical.

Blank Machinable End

  • The version shown here has a blank machinable end for easy adaptation to various actuating devices, including automated setups. Precision ground body (also available with a slightly oversize unground body to allow custom grinding to size).

*Order plunger and bushing seperately.
