Carr Lane Bullet-Nose Pins

Carr Lane’s Pivoting Hoist Rings rotate 180° but do not spin. The standard Pivoting Hoist Rings featured in this range are durable and economical, offering a low profile and high load capacity. These hoist rings come in five sizes, with load capacities ranging up to 20,000 lbs.

• Load rating (lbs): 900kg to 9,100kg
• Thread x minimum length: M8 x 25mm to M16 x 65mm
• Base: Forged 1045 steel, black oxide finish
• Safety factor = 5:1.

Range of Carr Lane Assemblies including Hand Knob, Swivel Washer and Knob Shoe avaible in a variety of sizes

• Metric and Imperial sizes
• Thread: 1/4-20 - 3/4-10 or M6 - M20

Durable swivel head screw designed to accommodate various swivel feet. The knurled head ensures a secure grip, allowing for easy hand tightening in light clamping tasks. Knurled-head swivel-screw assemblies that combine the bodies and feet also in this category, available in multiple sizes and materials. Swivel head screws are available in four different variants, which includes small foot, large foot, ball foot, and bodies for swivel had screws. These are available in steel, stainless steel and steel with black oxide finish.

• Thread: 1/4-20 - 5/8-11 or M6 - M16
• Metric and Imperial sizes
• Steel, Steel Black Oxide Finish and Stainless Steel

Precision Ball Lock Pins with a ground shank that is positive locking until released by pushing the button

These precision locating pins feature a chamfered tip for effortless part loading and a shoulder that helps resist downward forces. Typically, one Round Pin and one Diamond Pin are used together to locate two machined holes in a workpiece or to align two fixture components without causing binding.  The head and shank diameters of the round locating pins are concentric to within .0005" TIR. These pins are available with head diameters ranging from 1/4" to 1" (6 to 20mm in metric).

• Head Diameter: 1/4 - 1 or 6mm - 20mm
• Metric and Imperial sizes
• Round and Diamond pins

Slotted Locator Bushings are compatible with various alignment and locating pins to align two holes without binding. These precision bushings feature a tight tolerance in one direction and full relief in the perpendicular direction. . Available for pin diameters ranging from 3/16" to 1/2". An optional version in hardened 440C stainless steel is also available. These are available in knurled and press fit type.

Carr Lanes cone locating pin is designed to be used with the matching bushing. These pins are ideal for the fast assembly of two fixture parts, as they help accommodate significant misalignment. The pin's shank diameter and the bushing's outer diameter are precisely the same, enabling both fixture pieces to be bored for the installation hole simultaneously, ensuring enhanced accuracy. The mating bushing is paired with a Cone Locator Pin to align two pieces of a fixture.  These are offered with 1/2 and 3/4" shank diameters (12 and 20mm in metric).

• Pin and Bushing
• Available in imperial and metric sizes

A precision tooling ball serves as a reference for essential inspection, layout, and machining tasks. The shoulder type design includes a precision height-reference shoulder that ensures accurate three-dimensional positioning of the ball. The concentricity between the ball and shank is maintained within a tolerance of .0002" TIR. These balls are available in sizes of 1/4", 3/8", 1/2", and 3/4" (6mm, 12mm, and 20mm in metric), and are offered in both steel and stainless steel materials.

• Thread: #6-32 or M3.5
• Threaded and Un-Threaded
• Metric and Imperial
• Length: .47 - 1.50
