Carr Lane Lockscrews

• OD - 8 - 105mm
• ID RANGE - .35 - 85.00mm
• Metric sizes with a variety of lengths

L Pins and T Pins have precision-ground pin diameter to ensure accurate hole alignment. L Pins and T Pins are removable locating pins with a durable construction, each featuring a handle end with a small hole for attaching an optional cable. These pins come in a variety of diameters and lengths. Jig Pins, similar to L and T Pins, incorporate an integral shoulder to keep the handle raised.  Also available from the Carr Lane range, locking L Pins and T Pins with a lock screw that securely holds bushings in place. These pins are available in both imperial and metric sizes.

• Available in Imperial and Metric sizes.

Carr Lane offer various types of washers including flat washers, spherical washers and knurled face washers. Flat washers have a serrated surface designed to stop two parts from slipping relative to one another. Spherical Washers are robust two-piece washers designed to adjust when a stud and clamping surface are not perfectly perpendicular. These items are available in metric and imperial sizing as well as steel and stainless-steel options for selected products.

• Available in metric and imperial
• Available in steel and stainless steel

Carr Lane hand knobs are designed to provide an efficient and ergonomic method of manually adjusting and controlling machinery and applications HYQUIP supply the full range of Carr Lane Knobs including Star, Hand and Fluted, available in a variety of materials and sizes.

• Star, Hand and Fluted Knob designs
• Metric and Imperial sizes
• Thread: #10-32 - 5/8-11 or M6 - M12

The ideal fixture key for a wide range of applications. These keys are interchangeable, as they all fit into a standard 5/8" reamed hole. Easily mount any fixture on any machine tool by simply switching keys. No need to slot the underside of fixtures. Achieves concentricity with a tolerance of .0005" TIR or better. Secure the fixture from above or below using a hex wrench. Compatible with table-slot sizes ranging from 3/8" to 13/16" (12 to 22mm metric).

• Metric and Imperial sizes available
• Table Slot Size - 3/8 - 13/16 or 12mm - 22mm

Carr Lane locking-pin bushings are compatible with Locking L Pins, Locking T Pins and Locking Clamping Pins. They are equipped with a retainer spring clip on the inside diameter, and is compatible with all types of locking pins and locating screws. These precision bushings are designed to be press-fitted into a standard reamed hole and can be securely fastened with a lock screw to ensure the bushing remains in place.

• Available in Metric and Imperial sizes
• Available in sizes from 3/16" - 1/2" (6mm-12mm)

The threaded rest button features a hex head and is precision-machined to be .005 to .010" over the nominal height, allowing for finish grinding after installation. Screw rest buttons are ideal for use as supports and jig feet. They are available in thread sizes ranging from 1/4-20 to 1/2-13 (M6 to M12 in metric), with various height options to choose from.

• Thread: 1/4-20 - 1/2-13 or M6 - M12
• Metric and Imperial sizes
• Steel Black Oxide Finish

Carr Lane Head Press Fit Bushings are a variation of standard press fit bushings, featuring a head designed to withstand significant axial loads. These bushings are permanently installed into the jig plate and are typically used for single-operation drilling or reaming, where the bushings are not intended to be replaced throughout the tooling's lifespan. The head of these bushings can either remain exposed or be recessed by counterboring the installation hole.

• OD - 1-3/4"
• ID RANGE - 1.0000 - 1.3906"
• Imperial sizes available with a variety of Lengths
