Electronics - Diagnostics

The HYDAC ETS 1700 is an advanced electronic temperature switch designed for precise monitoring and control in hydraulic and tank systems. Featuring a 4-character display, 4 independently adjustable relay outputs, and selectable analogue output (4–20 mA or 0–10 V), it offers flexible integration and user-friendly operation via key programming.

• Measuring range¹) 0 .. +100 °C, (+32 .. 212 °F)
• Supply voltage: 22 .. 32 V DC
• Standard

Depending on the temperature range of the connected temperature sensor, the indication range of the ETS 1700 may be reduced

The HYDAC EDS 710 pressure switch offers accurate measurement up to 600 bar with minimal temperature error. Its compact, robust design and factory-set PNP output (N/O or N/C) ensure reliable performance in demanding industrial applications.

Key Features:

• Measuring ranges: 16; 60; 100; 250; 400; 600 bar
• Compensated temperature range -25 .. +85 °C
• Mechanical connection: G1/4 A DIN 3852
• Supply voltage 10 .. 30 V DC
• Torque value: 20 Nm

The HYDAC Portable Data Recorder HMG 4000 is a high-performance, user-friendly device designed for precise measurement and data acquisition in hydraulic systems. Featuring a large 5.7" full-colour touchscreen, it supports up to 38 sensors simultaneously and offers high-speed sampling, extensive storage, and real-time data visualisation deal for servicing, maintenance, and test bench applications.

Key Features:

• 5.7" Colour Touchscreen
• Up to 38 sensors can be connected
• Automatic Sensor Detection

The HYDAC ETS 3000 is a compact electronic temperature sensor with a digital display, designed for high-pressure applications up to 600 bar. It offers selectable analog outputs, dual switching outputs, and flexible mounting with a rotatable display for easy reading.

Key Features:

• Pressure resistance: 600 bar (18 mm) 50 bar (100, 250, 350 mm)
• Rotatable 4-digit display showing °C or °F
• Direct mounting into pipes or manifolds

The HYDAC EDS 810 pressure switch delivers accurate measurement up to 600 bar with minimal temperature and EMC effects. Its compact, robust design and factory-set N/O or N/C output ensure reliable performance for industrial and vehicle applications.

Key Features:

• Measuring ranges: 40; 60; 100; 160; 250; 400; 600 bar
• Compensated temperature range -25 .. +85 °C
• Compact, robust stainless steel sensor

Accessories for service instruments HMG 500 / 3000

• Case
• Power packs
• Connection adapters
• Connection cable
• Hydraulic adapter
• Rpm probe
• Sensor simulator

Sensors (accessories)

• Pressure transducer HDA 4748-H (with HSI sensor recognition)
• Temperature transmitter ETS 4548-H (with HSI sensor recognition)
• Flow rate transmitter EVS 31x0-H (with HSI sensor recognition)

The HYDAC ETS 3200 is a compact electronic temperature switch with an integrated sensor and 4-digit display, ideal for direct tank installation. It offers selectable analog output, dual switching outputs, and adjustable settings via a user-friendly keypad. Designed for flexible mounting, it supports various probe lengths and precise temperature control.

Key Features:

• Measuring range: -25 .. 100 °C (-13 ... 212 °F)
• Probe lengths: 100; 250; 350 mm
• Pressure resistance: 50 bar

The HYDAC ETS 3200 Pressure-Resistant model is a compact electronic temperature switch with a 4-digit display, designed for inline or hydraulic block mounting. With a robust 600 bar pressure rating and an integrated 18 mm probe, it offers reliable temperature monitoring, dual switching outputs, and selectable analog output for versatile applications.

Key Features:

• Probe length: 18 mm
• Pressure resistance: 600 bar
• Measuring range: -25 .. 100 °C (-13 ... 212 °F)

The HYDAC EDS 1700 electronic pressure switch, used in hydraulics and pneumatics, features an integrated pressure sensor, a 4-digit display, and four independently adjustable switching outputs for precise pressure monitoring. It allows easy configuration via a keypad, supports multiple units of measurement, and is designed for frequent switching cycles with high accuracy.

Key Features:

• Measuring ranges: 16; 40; 100; 250; 400; 600 bar
• Compensated temperature range: -10 .. +70 °C
• Operating temperature range: -25 .. +60 °C
• Storage temperature range: -25 .. +60 °C

The HYDAC ETS 3800 is a compact electronic temperature switch with a 4-digit LED display, designed for use with a separate temperature probe. With a wide measuring range of -30 to +150 °C and compatibility with the TFP 100 or standard PT 100 probes, it offers flexible installation and precise control through configurable outputs and user-friendly settings.

Key Features:

• Measuring range¹) -30 .. +150 °C (-22 .. 302 °F)
• Display: 4-digit, LED, 7 segment, red, height of digits 7 mm
• Connection, separate temperature probe Female cable connection: M12x1, 4 pole

Depending on the temperature range of the connected temperature sensor, the measurement range of the ETS 3800 may be reduced.

The HYDAC ETS 3800 with IO-Link is a compact electronic temperature switch featuring a 4-digit LED display and designed for use with a separate temperature probe. With a measuring range of -30 to +150 °C and IO-Link V1.1 communication, it enables seamless integration into modern automation systems, offering advanced parameterization and real-time data exchange.

Key Features:

• Measuring range¹) -30 . +150°C (-22 . 302°F)
• Display: 4-digit, LED, 7 segment, red, height of digits 7mm
• Connection, separate temperature probe Female cable connection: M12x1, 4 pole

Depending on the temp' range of the connected temp' sensor the measurement range of the ETS 3800 may be reduced.

The HYDAC ETS 3800 with VDMA menu navigation is a compact temperature switch for use with separate probes, offering a -30 to +150 °C range. It features intuitive setup, configurable outputs, and a rotatable 4-digit display for flexible installation.

Key Features:

• Measuring range¹) -30 .. +150°C (-22 .. 302°F)
• Display: 4-digit, LED, 7 segment, red, height of digits 7mm
• Connection, separate temp' probe Female cable connection: M12x1, 4 pole

Depending on the temp' range of the connected temp' sensor, the measurement range of the ETS 3800 may be reduced
